15A 125 VAC, (1) NEMA 5-15 Male (Plug) to (1) NEMA 5-15 Female (Connector), #12/3 Type SOOW, Extension
| Part Number | PE7000-xxx-515 |
|---|---|
| Functions | Power |
| Markets | Entertainment Industrial |
| Connector Type(s) | NEMA |
| Amperage | 15A |
| Data Sheet | Print / Save As |
| Rating: | 15 Amp, Single-phase (H,N,G), 2-pole, 3-wire, 125 VAC, 60 Hz |
|---|---|
| Male Plug: | (1) NEMA 5-15 (Edison), 15 Amp, 2-pole, 3-wire, 125 VAC, straight blade inline device, black |
| Cable/Cord: | #12/3 Type SOOW, Black |
| Length: | xxx = Length; 5', 10', 15', 25' or 50' Stock Lengths |
| Female Connector: | (1) NEMA 5-15 (Edison), 15 Amp, 2-pole, 3-wire, 125 VAC, straight blade inline device, black |
| Weight: | 0 lbs |
| Agency Approval: | UL Listed |
